AFARCO SMT

All parts are made from 100% Aluminum alloy 6061

AFARCO iRON PnP

contact.afarco@gmail.com

WhatsApp: +84 989 941 355

VARIETY CHOICES

yamaha Pneumatic feeder
30 positions
$2450
afarco Iron pnp

CONTACT.AFARCO@GMAIL.COM

yamaha Pneumatic feeder
30 positions
yamaha Pneumatic feeder
afarco Iron pnp
yamaha Electric feeder
and
30 positions
$2650

+84 989 941 355

afarco Iron pnp
SPECIAL
ONLY YAMAHA ELECTRIC FEEDER
30 POSITIONS
$2250

SHOP NOW

Shipping worldwide

BIG SALE!

Dear customers, in gratitude for your trust, we are pleased to send you special promotions of our company.
Up to 60% discount on shipping fees, when you order AFARCO iRON PnP Machine today.

 PRODUCT PARAMETERS

Material: All parts are made from 100% Aluminum alloy 6061

Total size:L550mm*W600mm*H45mm

Length of X-Axis Linear guide: 535mm

Length of Y-Axis Linear guide: 500mm

Platform size: 300mm*450mm

Net weight: 30kg

Power supply: Meanwell 24V ,14.6A

Input voltage: AC110V-AC220V

Feeder Type: Yamaha Feeder

Built-in HP mini Computer

Driver Stepper TB6600

Material: All parts are made from 100% Aluminum alloy 6061

PACK LIST

1. AFARCO CONTROL BOX

1.1 Mini Computer HP Core i3/i5, RAM 8GB, SSD 128G, WiFi (1PCS)

1.2 Smoothie Board AFARCO V2 (1PCS)

Use NXP LPC1769@120MHZ, It runs the open source smoothieware firmware. The built-in firmware version is the contribution of Mark, and You can get it here:
https://makr.zone/smoothieware-new-firmware-for-pnp/500/

1.3 AFARCO Control Auto Feeders 30 Channels (1PCS)

Use Microchip PIC16F887A with 30 feeder control outputs
Used for Yamaha Electric Feeder and Yamaha Pneumatic Feeder
USB communication uses FT232RL chipset

1.4 Power Supply Meanwell 24V 14.6A  (1PCS)

1.5 Vacuum pump -90KPa/24VDC (1PCS)

1.6 Solenoid Valve Airtac 24VDC (2PCS)

1.7 Bottom USB Camera + LED Camera (1PCS)

1.8 Nozzle Station 6 positions  (1PCS) ***

1.9 Driver Step TB6600 for Y-Axis  (2PCS)

https://youtu.be/NJCI-R4igMM?si=sooU6raYp6yvE9DI

2. Y-AXIS

2.1 Y-Axis Left (1PCS)

2.2 Y-Axis Right (1PCS)

https://youtu.be/0jI-fvsE2c4?si=HYwwAL93f6gffsmu

Aluminum alloy 6061
Linear Rail Hiwin MGN12H 500mm
Stepper Motor Nema23 (Step 57)
GT2 20 tooth pulley for 10mm belt
Belt 10mm

3. X-AXIS

3.1 X-Axis (1PCS)

https://youtu.be/0jI-fvsE2c4?si=HYwwAL93f6gffsmu

Aluminum alloy 6061
Linear Rail Hiwin MGN12H 535mm
Stepper Motor Nema17 (Step 42)
GT2 20 tooth pulley for 10mm belt
Belt 10mm

4. Z-AXIS

4.1 Z-Axis (1PCS)

Aluminum alloy 6061
Linear Rail Hiwin MGN 9C 100mm for N1-Axis and N2-Axis (2PCS)
Rotation Stepper Motor Nema11 (Step 28) (2PCS)
Vacuum coupling (2PCS)
CP45FV HOLDER (2PCS)
Top Camera USB + LED Camera (1PCS)
Driver TB6600 for Stepper Motor X, Stepper Motor Z, Stepper Motor N1, Stepper Motor N2

https://youtu.be/7W566hgoohw?si=wNMSD6ynmqI_XBOh

5. Yamaha Feeder Sole

5.1 Yamah Feeder Sole (2PCS)

Aluminum alloy 6061
Yamaha Feeder Sole (2PCS)
Jack GX-4 Male 12mm For Yamaha Feeder Electric (30PCS)
Solenoid Vacuum For Yamaha Feeder Pneumatic (30PCS)
Compressed Air cushion (30PCS)


**** 2 Options:

5.1.1 Yamah Feeder Electric and Yamaha Feeder Pneumatic

5.1.2 Yamah Feeder Pneumatic

https://youtu.be/m5yRQZz11qY?si=n0bH9E8cELYB-ZxZ

6. Nozzle Tips

Nozzle CP065 (2PCS)
Nozzle CP140 (2PCS)
Nozzle CP220/400  (2PCS)

6.1 Samsung Nozzle Set:

7. Screws and accessories

DB25 Cable (1PCS)
USB Camera Cable (1PCS)
Air duct  (2PCS)

7.1 Cables

7.2 Screws

SMOOTHIE BOARD - AFARCO DESIGN

NXP LPC1769@120MHZ CHIPSET

5 AXIS

5 OUTPUT

3 INPUT

USB COMMUNICATION

INPUT POWER SOURCE 24VDC

STORAGE CONFIGURATION ON MEMORY CARD

SIMPLE, EASY ASSEMBLY

STEP 1:

ONLY
TAKES
10
MINUTES

STEP 2:

Assemly Frame

Connect Signal Cable

You need to go to the OPENPNP official website to learn how to configure the OPENPNP software

https://openpnp.org/

YOUTUBE VIDEO

ORDER NOW

SEND IT NOW
